PEEK Suture Anchor

The product consists of an inserter, an anchor, and a suture, and the inserter consists of a handle and a rotary rod. The handle of the inserter is made of PC or ABS material, the material of the handle A is PC, and the material of the handle B and C is ABS. The inserter rod is made of 304 stainless steel (06Cr19Ni10) specified in GB/T 1220; Anchors are made of polyetheretherketone (OPTIMA LT3) material conforming to YY/T 0660 standard. The sutures were braided sutures made of ultra-high molecular weight polyethylene (UHMWPE) conforming to YY/T 1431 standard, and the blue dye was copper phthalocyanine. The product is sterilized by ethylene oxide and valid for 5 years.

Scope of application

Connection fixation of soft tissue to bone in the shoulders, knees, elbows, hips, feet, and ankles.

Product Features

★ The anchor is made of polyetheretherketone material, which has the characteristics of low elastic modulus, excellent mechanical properties, no artifacts under magnetic resonance imaging, reliable biocompatibility, etc.

★ Nail body strength is moderate, no stress shielding; The material has high stability and no allergic reaction to degradation.

★ The suture is mainly made of ultra-high molecular weight polyethylene fiber. The color is white, white and blue to ensure that the process of passing through the tendon tissue and tying is smoother, which is beneficial to suture management in clinical practice.

Product Advantages

• The hollow shape design allows the anchor to have high fixation force while providing the morphological basis for bone ingrowings;

• Less nail material, reducing the probability of foreign body reaction after implantation
